1.3 pbrt: System Overview

pbrt is structured using standard object-oriented techniques: for each of a number of fundamental types, the system specifies an interface that implementations of that type must fulfill. For example, pbrt requires the implementation of a particular shape that represents geometry in a scene to provide a set of methods including one that returns the shape’s bounding box, and another that tests for intersection with a given ray. In turn, the majority of the system can be implemented purely in terms of those interfaces; for example, the code that checks for occluding objects between a light source and a point being shaded calls the shape intersection methods without needing to consider which particular types of shapes are present in the scene.

There are a total of 14 of these key base types, summarized in Table 1.1. Adding a new implementation of one of these types to the system is straightforward; the implementation must provide the required methods, it must be compiled and linked into the executable, and the scene object creation routines must be modified to create instances of the object as needed as the scene description file is parsed. Section C.4 discusses extending the system in more detail.

Conventional practice in C++ would be to specify the interfaces for each of these types using abstract base classes that define pure virtual functions and to have implementations inherit from those base classes and implement the required virtual functions. In turn, the compiler would take care of generating the code that calls the appropriate method, given a pointer to any object of the base class type. That approach was used in the three previous versions of pbrt, but the addition of support for rendering on graphics processing units (GPUs) in this version motivated a more portable approach based on tag-based dispatch, where each specific type implementation is assigned a unique integer that determines its type at runtime. (See Section 1.5.7 for more information about this topic.) The polymorphic types that are implemented in this way in pbrt are all defined in header files in the base/ directory.

This version of pbrt is capable of running on GPUs that support C++17 and provide APIs for ray intersection tests. ^† We have carefully designed the system so that almost all of pbrt’s implementation runs on both CPUs and GPUs, just as it is presented in Chapters 2 through 12. We will therefore generally say little about the CPU versus the GPU in most of the following.

The main differences between the CPU and GPU rendering paths in pbrt are in their data flow and how they are parallelized—effectively, how the pieces are connected together. Both the basic rendering algorithm described later in this chapter and the light transport algorithms described in Chapters 13 and 14 are only available on the CPU. The GPU rendering pipeline is discussed in Chapter 15, though it, too, is also capable of running on the CPU (not as efficiently as the CPU-targeted light transport algorithms, however).

While pbrt can render many scenes well with its current implementation, it has frequently been extended by students, researchers, and developers. Throughout this section are a number of notable images from those efforts. Figures 1.13, 1.14, and 1.15 were each created by students in a rendering course where the final class project was to extend pbrt with new functionality in order to render an image that it could not have rendered before. These images are among the best from that course.

1.3.1 Phases of Execution

pbrt can be conceptually divided into three phases of execution. First, it parses the scene description file provided by the user. The scene description is a text file that specifies the geometric shapes that make up the scene, their material properties, the lights that illuminate them, where the virtual camera is positioned in the scene, and parameters to all the individual algorithms used throughout the system. The scene file format is documented on the pbrt website, pbrt.org.

The result of the parsing phase is an instance of the BasicScene class, which stores the scene specification, but not in a form yet suitable for rendering. In the second phase of execution, pbrt creates specific objects corresponding to the scene; for example, if a perspective projection has been specified, it is in this phase that a PerspectiveCamera object corresponding to the specified viewing parameters is created. Previous versions of pbrt intermixed these first two phases, but for this version we have separated them because the CPU and GPU rendering paths differ in some of the ways that they represent the scene in memory.

In the third phase, the main rendering loop executes. This phase is where pbrt usually spends the majority of its running time, and most of this book is devoted to code that executes during this phase. To orchestrate the rendering, pbrt implements an integrator, so-named because its main task is to evaluate the integral in Equation (1.1).

1.3.2 pbrt’s main() Function

The main() function for the pbrt executable is defined in the file cmd/pbrt.cpp in the directory that holds the pbrt source code, src/pbrt in the pbrt distribution. It is only a hundred and fifty or so lines of code, much of it devoted to processing command-line arguments and related bookkeeping.

Rather than operate on the argv values provided to the main() function directly, pbrt converts the provided arguments to a vector of std::strings. It does so not only for the greater convenience of the string class, but also to support non-ASCII character sets. Section B.3.2 has more information about character encodings and how they are handled in pbrt.

We will only include the definitions of some of the main function’s fragments in the book text here. Some, such as the one that handles parsing command-line arguments provided by the user, are both simple enough and long enough that they are not worth the few pages that they would add to the book’s length. However, we will include the fragment that declares the variables in which the option values are stored.

The GetCommandLineArguments() function and PBRTOptions type appear in a mini-index in the page margin, along with the number of the page where they are defined. The mini-indices have pointers to the definitions of almost all the functions, classes, methods, and member variables used or referred to on each page. (In the interests of brevity, we will omit very widely used classes such as Ray from the mini-indices, as well as types or methods that were just introduced in the preceding few pages.)

The PBRTOptions class stores various rendering options that are generally more suited to be specified on the command line rather than in scene description files—for example, how chatty pbrt should be about its progress during rendering. It is passed to the InitPBRT() function, which aggregates the various system-wide initialization tasks that must be performed before any other work is done. For example, it initializes the logging system and launches a group of threads that are used for the parallelization of pbrt.

After the arguments have been parsed and validated, the ParseFiles() function takes over to handle the first of the three phases of execution described earlier. With the assistance of two classes, BasicSceneBuilder and BasicScene, which are respectively described in Sections C.2 and C.3, it loops over the provided filenames, parsing each file in turn. If pbrt is run with no filenames provided, it looks for the scene description from standard input. The mechanics of tokenizing and parsing scene description files will not be described in this book, but the parser implementation can be found in the files parser.h and parser.cpp in the src/pbrt directory.

After the scene description has been parsed, one of two functions is called to render the scene. RenderWavefront() supports both the CPU and GPU rendering paths, processing a million or so image samples in parallel. It is the topic of Chapter 15. RenderCPU() renders the scene using an Integrator implementation and is only available when running on the CPU. It uses much less parallelism than RenderWavefront(), rendering only as many image samples as there are CPU threads in parallel.

Both of these functions start by converting the BasicScene into a form suitable for efficient rendering and then pass control to a processor-specific integrator. (More information about this process is available in Section C.3.) We will for now gloss past the details of this transformation in order to focus on the main rendering loop in RenderCPU(), which is much more interesting. For that, we will take the efficient scene representation as a given.

After the image has been rendered, CleanupPBRT() takes care of shutting the system down gracefully, including, for example, terminating the threads launched by InitPBRT().

1.3.3 Integrator Interface

In the RenderCPU() rendering path, an instance of a class that implements the Integrator interface is responsible for rendering. Because Integrator implementations only run on the CPU, we will define Integrator as a standard base class with pure virtual methods. Integrator and the various implementations are each defined in the files cpu/integrator.h and cpu/integrator.cpp.

The base Integrator constructor takes a single Primitive that represents all the geometric objects in the scene as well as an array that holds all the lights in the scene.

Each geometric object in the scene is represented by a Primitive, which is primarily responsible for combining a Shape that specifies its geometry and a Material that describes its appearance (e.g., the object’s color, or whether it has a dull or glossy finish). In turn, all the geometric primitives in a scene are collected into a single aggregate primitive that is stored in the Integrator::aggregate member variable. This aggregate is a special kind of primitive that itself holds references to many other primitives. The aggregate implementation stores all the scene’s primitives in an acceleration data structure that reduces the number of unnecessary ray intersection tests with primitives that are far away from a given ray. Because it implements the Primitive interface, it appears no different from a single primitive to the rest of the system.

Each light source in the scene is represented by an object that implements the Light interface, which allows the light to specify its shape and the distribution of energy that it emits. Some lights need to know the bounding box of the entire scene, which is unavailable when they are first created. Therefore, the Integrator constructor calls their Preprocess() methods, providing those bounds. At this point any “infinite” lights are also stored in a separate array. This sort of light, which will be introduced in Section 12.5, models infinitely far away sources of light, which is a reasonable model for skylight as received on Earth’s surface, for example. Sometimes it will be necessary to loop over just those lights, and for scenes with thousands of light sources it would be inefficient to loop over all of them just to find those.

Integrators must provide an implementation of the Render() method, which takes no further arguments. This method is called by the RenderCPU() function once the scene representation has been initialized. The task of integrators is to render the scene as specified by the aggregate and the lights. Beyond that, it is up to the specific integrator to define what it means to render the scene, using whichever other classes that it needs to do so (e.g., a camera model). This interface is intentionally very general to permit a wide range of implementations—for example, one could implement an Integrator that measures light only at a sparse set of points distributed through the scene rather than generating a regular 2D image.

The Integrator class provides two methods related to ray–primitive intersection for use of its subclasses. Intersect() takes a ray and a maximum parametric distance tMax, traces the given ray into the scene, and returns a ShapeIntersection object corresponding to the closest primitive that the ray hit, if there is an intersection along the ray before tMax. (The ShapeIntersection structure is defined in Section 6.1.3.) One thing to note is that this method uses the type pstd::optional for the return value rather than std::optional from the C++ standard library; we have reimplemented parts of the standard library in the pstd namespace for reasons that are discussed in Section 1.5.5.

Also note the capitalized floating-point type Float in Intersect()’s signature: almost all floating-point values in pbrt are declared as Floats. (The only exceptions are a few cases where a 32-bit float or a 64-bit double is specifically needed (e.g., when saving binary values to files).) Depending on the compilation flags of pbrt, Float is an alias for either float or double, though single precision float is almost always sufficient in practice. The definition of Float is in the pbrt.h header file, which is included by all other source files in pbrt.

Integrator::IntersectP() is closely related to the Intersect() method. It checks for the existence of intersections along the ray but only returns a Boolean indicating whether an intersection was found. (The “P” in its name indicates that it is a function that evaluates a predicate, using a common naming convention from the Lisp programming language.) Because it does not need to search for the closest intersection or return additional geometric information about intersections, IntersectP() is generally more efficient than Integrator::Intersect(). This routine is used for shadow rays.

1.3.4 ImageTileIntegrator and the Main Rendering Loop

Before implementing a basic integrator that simulates light transport to render an image, we will define two Integrator subclasses that provide additional common functionality used by that integrator as well as many of the integrator implementations to come. We start with ImageTileIntegrator, which inherits from Integrator. The next section defines RayIntegrator, which inherits from ImageTileIntegrator.

All of pbrt’s CPU-based integrators render images using a camera model to define the viewing parameters, and all parallelize rendering by splitting the image into tiles and having different processors work on different tiles. Therefore, pbrt includes an ImageTileIntegrator that provides common functionality for those tasks.

In addition to the aggregate and the lights, the ImageTileIntegrator constructor takes a Camera that specifies the viewing and lens parameters such as position, orientation, focus, and field of view. Film stored by the camera handles image storage. The Camera classes are the subject of most of Chapter 5, and Film is described in Section 5.4. The Film is responsible for writing the final image to a file.

The constructor also takes a Sampler; its role is more subtle, but its implementation can substantially affect the quality of the images that the system generates. First, the sampler is responsible for choosing the points on the image plane that determine which rays are initially traced into the scene. Second, it is responsible for supplying random sample values that are used by integrators for estimating the value of the light transport integral, Equation (1.1). For example, some integrators need to choose random points on light sources to compute illumination from area lights. Generating a good distribution of these samples is an important part of the rendering process that can substantially affect overall efficiency; this topic is the main focus of Chapter 8.

For all of pbrt’s integrators, the final color computed at each pixel is based on random sampling algorithms. If each pixel’s final value is computed as the average of multiple samples, then the quality of the image improves. At low numbers of samples, sampling error manifests itself as grainy high-frequency noise in images, though error goes down at a predictable rate as the number of samples increases. (This topic is discussed in more depth in Section 2.1.4.) ImageTileIntegrator::Render() therefore renders the image in waves of a few samples per pixel. For the first two waves, only a single sample is taken in each pixel. In the next wave, two samples are taken, with the number of samples doubling after each wave up to a limit. While it makes no difference to the final image if the image was rendered in waves or with all the samples being taken in a pixel before moving on to the next one, this organization of the computation means that it is possible to see previews of the final image during rendering where all pixels have some samples, rather than a few pixels having many samples and the rest having none.

Because pbrt is parallelized to run using multiple threads, there is a balance to be struck with this approach. There is a cost for threads to acquire work for a new image tile, and some threads end up idle at the end of each wave once there is no more work for them to do but other threads are still working on the tiles they have been assigned. These considerations motivated the capped doubling approach.

Before rendering begins, a few additional variables are required. First, the integrator implementations will need to allocate small amounts of temporary memory to store surface scattering properties in the course of computing each ray’s contribution. The large number of resulting allocations could easily overwhelm the system’s regular memory allocation routines (e.g., new), which must coordinate multi-threaded maintenance of elaborate data structures to track free memory. A naive implementation could potentially spend a fairly large fraction of its computation time in the memory allocator.

To address this issue, pbrt provides a ScratchBuffer class that manages a small preallocated buffer of memory. ScratchBuffer allocations are very efficient, just requiring the increment of an offset. The ScratchBuffer does not allow independently freeing allocations; instead, all must be freed at once, but doing so only requires resetting that offset.

Because ScratchBuffers are not safe for use by multiple threads at the same time, an individual one is created for each thread using the ThreadLocal template class. Its constructor takes a lambda function that returns a fresh instance of the object of the type it manages; here, calling the default ScratchBuffer constructor is sufficient. ThreadLocal then handles the details of maintaining distinct copies of the object for each thread, allocating them on demand.

Most Sampler implementations find it useful to maintain some state, such as the coordinates of the current pixel. This means that multiple threads cannot use a single Sampler concurrently and ThreadLocal is also used for Sampler management. Samplers provide a Clone() method that creates a new instance of their sampler type. The Sampler first provided to the ImageTileIntegrator constructor, samplerPrototype, provides those copies here.

It is helpful to provide the user with an indication of how much of the rendering work is done and an estimate of how much longer it will take. This task is handled by the ProgressReporter class, which takes as its first parameter the total number of items of work. Here, the total amount of work is the number of samples taken in each pixel times the total number of pixels. It is important to use 64-bit precision to compute this value, since a 32-bit int may be insufficient for high-resolution images with many samples per pixel.

In the following, the range of samples to be taken in the current wave is given by waveStart and waveEnd; nextWaveSize gives the number of samples to be taken in the next wave.

With these variables in hand, rendering proceeds until the required number of samples have been taken in all pixels.

The ParallelFor2D() function loops over image tiles, running multiple loop iterations concurrently; it is part of the parallelism-related utility functions that are introduced in Section B.6. A C++ lambda expression provides the loop body. ParallelFor2D() automatically chooses a tile size to balance two concerns: on one hand, we would like to have significantly more tiles than there are processors in the system. It is likely that some of the tiles will take less processing time than others, so if there was for example a 1:1 mapping between processors and tiles, then some processors will be idle after finishing their work while others continue to work on their region of the image. (Figure 1.17 graphs the distribution of time taken to render tiles of an example image, illustrating this concern.) On the other hand, having too many tiles also hurts efficiency. There is a small fixed overhead for a thread to acquire more work in the parallel for loop and the more tiles there are, the more times this overhead must be paid. ParallelFor2D() therefore chooses a tile size that accounts for both the extent of the region to be processed and the number of processors in the system.

Given a tile to render, the implementation starts by acquiring the ScratchBuffer and Sampler for the currently executing thread. As described earlier, the ThreadLocal::Get() method takes care of the details of allocating and returning individual ones of them for each thread.

With those in hand, the implementation loops over all the pixels in the tile using a range-based for loop that uses iterators provided by the Bounds2 class before informing the ProgressReporter about how much work has been completed.

Given a pixel to take one or more samples in, the thread’s Sampler is notified that it should start generating samples for the current pixel via StartPixelSample(), which allows it to set up any internal state that depends on which pixel is currently being processed. The integrator’s EvaluatePixelSample() method is then responsible for determining the specified sample’s value, after which any temporary memory it may have allocated in the ScratchBuffer is freed with a call to ScratchBuffer::Reset().

Having provided an implementation of the pure virtual Integrator::Render() method, ImageTileIntegrator now imposes the requirement on its subclasses that they implement the following EvaluatePixelSample() method.

After the parallel for loop for the current wave completes, the range of sample indices to be processed in the next wave is computed.

If the user has provided the –write-partial-images command-line option, the in-progress image is written to disk before the next wave of samples is processed. We will not include here the fragment that takes care of this, <<Optionally write current image to disk>>.

1.3.5 RayIntegrator Implementation

Just as the ImageTileIntegrator centralizes functionality related to integrators that decompose the image into tiles, RayIntegrator provides commonly used functionality to integrators that trace ray paths starting from the camera. All of the integrators implemented in Chapters 13 and 14 inherit from RayIntegrator.

Its constructor does nothing more than pass along the provided objects to the ImageTileIntegrator constructor.

RayIntegrator implements the pure virtual EvaluatePixelSample() method from ImageTileIntegrator. At the given pixel, it uses its Camera and Sampler to generate a ray into the scene and then calls the Li() method, which is provided by the subclass, to determine the amount of light arriving at the image plane along that ray. As we will see in following chapters, the units of the value returned by this method are related to the incident spectral radiance at the ray origin, which is generally denoted by the symbol in equations—thus, the method name. This value is passed to the Film, which records the ray’s contribution to the image.

Figure 1.18 summarizes the main classes used in this method and the flow of data among them.

Each ray carries radiance at a number of discrete wavelengths (four, by default). When computing the color at each pixel, pbrt chooses different wavelengths at different pixel samples so that the final result better reflects the correct result over all wavelengths. To choose these wavelengths, a sample value lu is first provided by the Sampler. This value will be uniformly distributed and in the range . The Film::SampleWavelengths() method then maps this sample to a set of specific wavelengths, taking into account its model of film sensor response as a function of wavelength. Most Sampler implementations ensure that if multiple samples are taken in a pixel, those samples are in the aggregate well distributed over . In turn, they ensure that the sampled wavelengths are also well distributed across the range of valid wavelengths, improving image quality.

The CameraSample structure records the position on the film for which the camera should generate a ray. This position is affected by both a sample position provided by the sampler and the reconstruction filter that is used to filter multiple sample values into a single value for the pixel. GetCameraSample() handles those calculations. CameraSample also stores a time that is associated with the ray as well as a lens position sample, which are used when rendering scenes with moving objects and for camera models that simulate non-pinhole apertures, respectively.

The Camera interface provides two methods to generate rays: GenerateRay(), which returns the ray for a given image sample position, and GenerateRayDifferential(), which returns a ray differential, which incorporates information about the rays that the camera would generate for samples that are one pixel away on the image plane in both the and directions. Ray differentials are used to get better results from some of the texture functions defined in Chapter 10, by making it possible to compute how quickly a texture varies with respect to the pixel spacing, which is a key component of texture antialiasing.

Some CameraSample values may not correspond to valid rays for a given camera. Therefore, pstd::optional is used for the CameraRayDifferential returned by the camera.

If the camera ray is valid, it is passed along to the RayIntegrator subclass’s Li() method implementation after some additional preparation. In addition to returning the radiance along the ray L, the subclass is also responsible for initializing an instance of the VisibleSurface class, which records geometric information about the surface the ray intersects (if any) at each pixel for the use of Film implementations like the GBufferFilm that store more information than just color at each pixel.

Before the ray is passed to the Li() method, the ScaleDifferentials() method scales the differential rays to account for the actual spacing between samples on the film plane when multiple samples are taken per pixel.

For Film implementations that do not store geometric information at each pixel, it is worth saving the work of populating the VisibleSurface class. Therefore, a pointer to this class is only passed in the call to the Li() method if it is necessary, and a null pointer is passed otherwise. Integrator implementations then should only initialize the VisibleSurface if it is non-null.

CameraRayDifferential also carries a weight associated with the ray that is used to scale the returned radiance value. For simple camera models, each ray is weighted equally, but camera models that more accurately simulate the process of image formation by lens systems may generate some rays that contribute more than others. Such a camera model might simulate the effect of less light arriving at the edges of the film plane than at the center, an effect called vignetting.

Li() is a pure virtual method that RayIntegrator subclasses must implement. It returns the incident radiance at the origin of a given ray, sampled at the specified wavelengths.

A common side effect of bugs in the rendering process is that impossible radiance values are computed. For example, division by zero results in radiance values equal to either the IEEE floating-point infinity or a “not a number” value. The renderer looks for these possibilities and prints an error message when it encounters them. Here we will not include the fragment that does this, <<Issue warning if unexpected radiance value is returned>>. See the implementation in cpu/integrator.cpp if you are interested in its details.

After the radiance arriving at the ray’s origin is known, a call to Film::AddSample() updates the corresponding pixel in the image, given the weighted radiance for the sample. The details of how sample values are recorded in the film are explained in Sections 5.4 and 8.8.

1.3.6 Random Walk Integrator

Although it has taken a few pages to go through the implementation of the integrator infrastructure that culminated in RayIntegrator, we can now turn to implementing light transport integration algorithms in a simpler context than having to start implementing a complete Integrator::Render() method. The RandomWalkIntegrator that we will describe in this section inherits from RayIntegrator and thus all the details of multi-threading, generating the initial ray from the camera and then adding the radiance along that ray to the image, are all taken care of. The integrator operates in a simpler context: a ray has been provided and its task is to compute the radiance arriving at its origin.

Recall that in Section 1.2.7 we mentioned that in the absence of participating media, the light carried by a ray is unchanged as it passes through free space. We will ignore the possibility of participating media in the implementation of this integrator, which allows us to take a first step: given the first intersection of a ray with the geometry in the scene, the radiance arriving at the ray’s origin is equal to the radiance leaving the intersection point toward the ray’s origin. That outgoing radiance is given by the light transport equation (1.1), though it is hopeless to evaluate it in closed form. Numerical approaches are required, and the ones used in pbrt are based on Monte Carlo integration, which makes it possible to estimate the values of integrals based on pointwise evaluation of their integrands. Chapter 2 provides an introduction to Monte Carlo integration, and additional Monte Carlo techniques will be introduced as they are used throughout the book.

In order to compute the outgoing radiance, the RandomWalkIntegrator implements a simple Monte Carlo approach that is based on incrementally constructing a random walk, where a series of points on scene surfaces are randomly chosen in succession to construct light-carrying paths starting from the camera. This approach effectively models image formation in the real world in reverse, starting from the camera rather than from the light sources. Going backward in this respect is still physically valid because the physical models of light that pbrt is based on are time-reversible.

Although the implementation of the random walk sampling algorithm is in total just over twenty lines of code, it is capable of simulating complex lighting and shading effects; Figure 1.19 shows an image rendered using it. (That image required many hours of computation to achieve that level of quality, however.) For the remainder of this section, we will gloss over a few of the mathematical details of the integrator’s implementation and focus on an intuitive understanding of the approach, though subsequent chapters will fill in the gaps and explain this and more sophisticated techniques more rigorously.

This integrator recursively evaluates the random walk. Therefore, its Li() method implementation does little more than start the recursion, via a call to the LiRandomWalk() method. Most of the parameters to Li() are just passed along, though the VisibleSurface is ignored for this simple integrator and an additional parameter is added to track the depth of recursion.

The first step is to find the closest intersection of the ray with the shapes in the scene. If no intersection is found, the ray has left the scene. Otherwise, a SurfaceInteraction that is returned as part of the ShapeIntersection structure provides information about the local geometric properties of the intersection point.

If no intersection was found, radiance still may be carried along the ray due to light sources such as the ImageInfiniteLight that do not have geometry associated with them. The Light::Le() method allows such lights to return their radiance for a given ray.

If a valid intersection has been found, we must evaluate the light transport equation at the intersection point. The first term, , which is the emitted radiance, is easy: emission is part of the scene specification and the emitted radiance is available by calling the SurfaceInteraction::Le() method, which takes the outgoing direction of interest. Here, we are interested in radiance emitted back along the ray’s direction. If the object is not emissive, that method returns a zero-valued spectral distribution.

Evaluating the second term of the light transport equation requires computing an integral over the sphere of directions around the intersection point . Application of the principles of Monte Carlo integration can be used to show that if directions are chosen with equal probability over all possible directions, then an estimate of the integral can be computed as a weighted product of the BSDF , which describes the light scattering properties of the material at , the incident lighting, , and a cosine factor:

In other words, given a random direction , estimating the value of the integral requires evaluating the terms in the integrand for that direction and then scaling by a factor of . (This factor, which is derived in Section A.5.2, relates to the surface area of a unit sphere.) Since only a single direction is considered, there is almost always error in the Monte Carlo estimate compared to the true value of the integral. However, it can be shown that estimates like this one are correct in expectation: informally, that they give the correct result on average. Averaging multiple independent estimates generally reduces this error—hence, the practice of taking multiple samples per pixel.

The BSDF and the cosine factor of the estimate are easily evaluated, leaving us with , the incident radiance, unknown. However, note that we have found ourselves right back where we started with the initial call to LiRandomWalk(): we have a ray for which we would like to find the incident radiance at the origin—that, a recursive call to LiRandomWalk() will provide.

Before computing the estimate of the integral, we must consider terminating the recursion. The RandomWalkIntegrator stops at a predetermined maximum depth, maxDepth. Without this termination criterion, the algorithm might never terminate (imagine, e.g., a hall-of-mirrors scene). This member variable is initialized in the constructor based on a parameter that can be set in the scene description file.

If the random walk is not terminated, the SurfaceInteraction::GetBSDF() method is called to find the BSDF at the intersection point. It evaluates texture functions to determine surface properties and then initializes a representation of the BSDF. It generally needs to allocate memory for the objects that constitute the BSDF’s representation; because this memory only needs to be active when processing the current ray, the ScratchBuffer is provided to it to use for its allocations.

Next, we need to sample a random direction to compute the estimate in Equation (1.2). The SampleUniformSphere() function returns a uniformly distributed direction on the unit sphere, given two uniform values in that are provided here by the sampler.

All the factors of the Monte Carlo estimate other than the incident radiance can now be readily evaluated. The BSDF class provides an f() method that evaluates the BSDF for a pair of specified directions, and the cosine of the angle with the surface normal can be computed using the AbsDot() function, which returns the absolute value of the dot product between two vectors. If the vectors are normalized, as both are here, this value is equal to the absolute value of the cosine of the angle between them (Section 3.3.2).

It is possible that the BSDF will be zero-valued for the provided directions and thus that fcos will be as well—for example, the BSDF is zero if the surface is not transmissive but the two directions are on opposite sides of it. ^† In that case, there is no reason to continue the random walk, since subsequent points will make no contribution to the result.

The remaining task is to compute the new ray leaving the surface in the sampled direction . This task is handled by the SpawnRay() method, which returns a ray leaving an intersection in the provided direction, ensuring that the ray is sufficiently offset from the surface that it does not incorrectly reintersect it due to round-off error. Given the ray, the recursive call to LiRandomWalk() can be made to estimate the incident radiance, which completes the estimate of Equation (1.2).

This simple approach has many shortcomings. For example, if the emissive surfaces are small, most ray paths will not find any light and many rays will need to be traced to form an accurate image. In the limit case of a point light source, the image will be black, since there is zero probability of intersecting such a light source. Similar issues apply with BSDF models that scatter light in a concentrated set of directions. In the limiting case of a perfect mirror that scatters incident light along a single direction, the RandomWalkIntegrator will never be able to randomly sample that direction.

Those issues and more can be addressed through more sophisticated application of Monte Carlo integration techniques. In subsequent chapters, we will introduce a succession of improvements that lead to much more accurate results. The integrators that are defined in Chapters 13 through 15 are the culmination of those developments. All still build on the same basic ideas used in the RandomWalkIntegrator, but are much more efficient and robust than it is. Figure 1.20 compares the RandomWalkIntegrator to one of the improved integrators and gives a sense of how much improvement is possible.
